Turbo Features
- 300hp - 550hp application
- Gamma-Ti turbine wheel
- Dual ceramic ball bearing assembly with metal cage
- Forged milled extended tip compressor wheel
- Stainless steel turbine housing
- Water cooled bearing housing
- Large internal wastegate
- Compressor recirculation valve (a.k.a BOV)
- Boost solenoid valve
- Standard T3 or T4 mounting flange (depending on part number)
This is a Super Core which means it consist of the center section, turbine wheel, compressor housing and billet compressor wheel. Make sure to add in addition to the super core which size exhaust housing you would like to use. You will need both to make a complete turbo.
Compressor Wheel Size 52/70mm
Turbine Wheel Size 64mm
Not Included With Turbo Assemblies
- Speed sensor
- Turbine outlet v-band
- Turbine inlet gasket
- Water port fittings
- Oil drain gasket or drain port fitting
